Ceramic Pcb Supplier

Benefits:
Ceramic PCBs are known for their high thermal conductivity, low thermal expansion coefficient, and high mechanical strength. These properties make them suitable for use in demanding applications where electronic components are exposed to high temperatures and stresses. Some of the benefits of using ceramic PCBs include:

– High thermal conductivity: Ceramic PCBs provide efficient heat dissipation, which reduces the risk of component failure due to overheating.
– Low thermal expansion coefficient: Ceramic PCBs remain stable at high temperatures, which prevents thermal stress from damaging the components.
– High mechanical strength: Ceramic PCBs are resistant to physical stress, vibration, and impact, which increases their durability and reliability.

Features:
Ceramic PCBs are made from a ceramic material such as alumina or aluminum nitride, which provides the following features:

– High thermal conductivity (>170 W/mK for aluminum nitride)
– Low thermal expansion coefficient (1000°C)
– Compatibility with thick-film and thin-film processes

Specifications:
Our ceramic PCB supplier offers a wide range of specifications to meet the requirements of different applications. Some of the specifications available include:

– Material: Alumina, aluminum nitride, or other ceramics
– Thickness: 0.2 mm to 2.0 mm
– Copper thickness: 1 oz to 6 oz
– Minimum hole size: 0.15 mm
– Minimum line width/spacing: 0.1 mm
– Maximum operating temperature: >1000°C

Applications:
Ceramic PCBs are used in a variety of applications where high thermal conductivity and mechanical strength are required. Some of the common applications include:

– LED lighting: The high thermal conductivity of ceramic PCBs makes them ideal for use in LED modules and lighting systems.
– Power electronics: Ceramic PCBs can handle high currents and voltages, making them suitable for power supplies, converters, and inverters.
– Aerospace and defense: Ceramic PCBs can withstand the extreme temperatures and vibrations of aerospace and defense applications, such as avionics, radar, and communication systems.
– Medical devices: Ceramic PCBs are biocompatible and can be sterilized, making them ideal for medical devices such as implantable sensors and pacemakers.

FAQ:
Q: What is a ceramic PCB?
A: A ceramic PCB is a printed circuit board made from a ceramic material such as alumina or aluminum nitride.

Q: What are the benefits of using ceramic PCBs?
A: Ceramic PCBs offer high thermal conductivity, low thermal expansion coefficient, and high mechanical strength, which makes them suitable for use in demanding applications where electronics are exposed to high temperatures and stresses.

Q: What are the specifications of ceramic PCBs?
A: The specifications of ceramic PCBs include material, thickness, copper thickness, minimum hole size, minimum line width/spacing, and maximum operating temperature.

Q: What are some of the applications of ceramic PCBs?
A: Ceramic PCBs are used in LED lighting, power electronics, aerospace and defense, and medical devices, among other applications
