Mold Laser Welding Machine

Benefits
The mold laser welding machine offers numerous benefits to its users, including:

1. High precision and accuracy: The machine ensures precise and accurate welding, resulting in minimal distortion and a high-quality finish.
2. Time and cost savings: The mold laser welding machine significantly reduces the time and cost associated with traditional welding methods, such as TIG welding.
3. Minimal heat input: The machine’s low heat input ensures minimal thermal stress on the mold, reducing the risk of deformation and damage.
4. Enhanced mold life: The high-quality welds produced by the machine extend the life of the mold, reducing the need for frequent replacements.
5. Versatility: The machine is suitable for a wide range of materials, including steel, aluminum, and copper alloys.

Features
The mold laser welding machine comes with several advanced features, such as:

1. User-friendly interface: The machine’s intuitive control panel allows for easy operation and programming.
2. High-speed laser: The high-speed laser ensures quick and efficient welding, reducing downtime.
3. Adjustable parameters: Users can easily adjust the machine’s parameters, such as pulse width, frequency, and power, to achieve the desired welding results.
4. Compact design: The machine’s compact design allows for easy integration into existing production lines.
5. Safety features: The machine is equipped with safety features, such as an emergency stop button and protective housing, to ensure the safety of the operator.

Specifications
1. Laser type: Fiber or Nd:YAG
2. Laser power: 200W – 400W
3. Wavelength: 1064nm
4. Pulse width: 0.1 – 20ms
5. Pulse frequency: 0.5 – 30Hz
6. Welding depth: 0.1 – 3mm
7. Cooling system: Water cooling
8. Power supply: 220V, 50/60Hz

Applications
The mold laser welding machine is suitable for various applications, including:

1. Repair and maintenance of injection molds, die-casting molds, and stamping molds.
2. Welding of small and complex parts, such as sensors, connectors, and medical devices.
3. Joining of dissimilar materials, such as steel and aluminum.
4. Surface treatment, such as hardening and cladding.

FAQ
1. What materials can be welded with the mold laser welding machine?
The machine is suitable for a wide range of materials, including steel, aluminum, and copper alloys.

2. Is the machine easy to operate?
Yes, the machine’s user-friendly interface and intuitive control panel make it easy to operate and program.

3. What is the typical welding depth of the machine?
The welding depth can range from 0.1mm to 3mm, depending on the material and machine settings.

4. Can the machine be used for surface treatment?
Yes, the mold laser welding machine can be used for surface treatment, such as hardening and cladding.

5. What type of cooling system does the machine use?
The machine uses a water cooling system to maintain optimal performance and prevent overheating.
